Description
Camera
- Image Sensor: 1/2.7″ Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV:
- 2.8 mm: Horizontal FOV 113°, Vertical FOV 62°, Diagonal FOV 134°
- 4 mm: Horizontal FOV 90°, Vertical FOV 49°, Diagonal FOV 108°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
DORI
- 2.8 mm: D: 79 m, O: 31 m, R: 15 m, I: 7 m
- 4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m
Illuminator
- Supplement Light Type: IR
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video
- Main Stream (50 Hz): 12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Main Stream (60 Hz): 15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream (50 Hz): 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
- Sub-Stream (60 Hz): 15 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression: Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline Profile, Main Profile, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- Region of Interest (ROI): 1 fixed region for main stream
Audio
- Audio Type: Mono sound
- Environment Noise Filtering: Yes
- Audio Sampling Rate: 8 kHz/16 kHz
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711ulaw), 64 Kbps (G.711alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 160 Kbps (MP2L2), 16 to 64 Kbps (AAC-LC)
Network
- Security: Password protection, complicated password, watermark, authentication options
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, T, G), ISAPI, SDK
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
- User/Host: Up to 32 users, 3 user levels: administrator, operator, user
- Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
Interface
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- Built-in Microphone: Yes
- Reset Key: Yes
Event
- Basic Event: Motion detection, video tampering alarm, exception
- Smart Event: Line crossing detection, intrusion detection
- Linkage: Upload to FTP/memory card, send email, notify surveillance center
General
- Power: 12 VDC ± 25%, 0.41 A, max. 5 W, PoE: IEEE 802.3af, Class 3, max. 6.5 W
- Material: Metal
- Dimension: Ø127.3 mm × 95.9 mm
- Package Dimension: 150 mm × 150 mm × 141 mm
- Weight: Approx. 600 g
- With Package Weight: Approx. 909 g
- Storage Conditions: -30 °C to 60 °C, Humidity 95% or less
- Startup and Operating Conditions: -30 °C to 60 °C, Humidity 95% or less
- Language: English, Ukrainian
- General Function: Heartbeat, anti-banding, mirror, password protection
Approval
- EMC: CE-EMC, RCM, IC
- Safety: UL, CB, CE-LVD, BIS
- Environment: CE-RoHS, WEEE, Reach
- Protection: IP67
